1.Frequency 9410±30MHz
2.Transceiver Type HTR-X04
3.Output Power 4KW
4.Pulse Length 0.045,0.07,0.13,0.2,0.3,0.4,0.8,1.2
5.Frequency（Hz） 3000，1500 ，1000 ，750
6.Noise Figure 5dB
7.Tune Auto/Manual
8.IF 60MHz，Logarithmic
9.IF Bandwidth 28/7/3 MHz
10.Sensitivity - 100dBm
11.Dynamic range 100dB
12.Gain Auto
13.Anti-sea Auto/Manual
14.Anti-rain/snow Auto/Manual
15.Minimum range 25m（0.75NM range scale）
Noto：Antenna height 15m，target size 10㎡，target height 3 m
16.Range Discrimination 15m（0.75NM range scale）
Noto：Antenna height 15m，target size 10㎡，target height 3 m
